Page - 70/79 AF6ZP0AL - COMBIAC0 & ACE0 - User Manual
Error code Description Effect
Machine status
when the test is
done
Restart
procedure
Coil shor. Ev. - MDI
CAN 76
Shortcircuit on On/off valves coil On/off valves stopped start-up, stby,
during valve
function
valve on/off request
EV1/5 driver shorted
- 74
EV1 or EV2 on/off valve drivers
shorted (always ON)
On/off valves stopped start-up, stby valve on/off request
EV2 driver shorted -
MDI CAN 74
EV2 on/off valve driver shorted
(always ON)
On/off valves stopped start-up, stby valve on/off request
EV3 driver shorted -
MDI CAN 74
EV3 on/off valve driver shorted
(always ON)
On/off valves stopped start-up, stby valve on/off request
EV4 driver shorted -
MDI CAN 74
EV4 on/off valve driver shorted
(always ON)
On/off valves stopped start-up, stby valve on/off request
Evp1 not ok - MDI
CAN 48
Evp driver open (not able to close,
so not able to drive the valve)
Evp stopped during Evp
function
valve evp request
Evp2 not ok - MDI
CAN 47
Evp2 driver open (not able to close,
so not able to drive the valve)
Evp stopped during Evp
function
valve evp request
Pump I NO zero -
MDI CAN 56
Pump chopper current sensor
feedback is out of permitted stby
range
Pump motor stopped start-up, stby pump request
Pump I=0 ever -
MDI CAN 52
Pump current feedback is always
0A even when pump motor is
running
Pump motor stopped pump function pump request
lift+lower - 49 lift+lower request Pump motor stopped continuous hydraulic request
Cont. Drv. Ev1 - MDI
CAN 75
Driver of Ev1 is open, not able to
close
Ev1 stopped during Ev1
function
valve Ev1 request
Cont. Drv. Ev2 - MDI
CAN 75
Driver of Ev2 is open, not able to
close
Ev2 stopped during Ev2
function
valve Ev2 request
Cont. Drv. Ev3 - MDI
CAN 75
Driver of Ev3 is open, not able to
close
Ev3 stopped during Ev3
function
valve Ev3 request
Cont. Drv. Ev4 - MDI
CAN 75
Driver of Ev4 is open, not able to
close
Ev4 stopped during Ev4
function
valve Ev4 request
Cont. Drv. Ev5 - MDI
CAN 75
Driver of Ev5 is open, not able to
close
Ev5 stopped during Ev5
function
valve Ev5 request
Pump Vacc not OK -
MDI CAN 89
The pump accelerator value is
higher than the minimum value
recorded, and the lift/lower
switches are open
Pump stopped Continuous Pump request
Sens. Mot. Temp.
KO - MDI CAN 67
The motor temperature sensor is
damaged
Performance highly
reduced
Continuous Key-on recycle
BACKING INPUT -
MDI CAN 78
An inching request is performed
and the tiller input is active, or FW
or REV input is active
Traction is stopped
start-up, stand-
by, traction
traction request
To Next Page
