10.9 CONFIG MENU: "SET MODEL"
This adjustment selects the steering configuration. For a tacho-generator (or a stepper
motor) controlled steering the only permissable settings are 0 and 1:
- Level 0: tacho-generator (or stepper motor) steering
- Level 1: tacho-generator (or stepper motor) steering plus automatic centering
- Level 2: two pots manual steering (logic modification required)
- Level 3: two pots manual steering plus automatic centering (logic modification
required)
Note: a new SET MODEL value will be acquired only after the key is switched off.
10.10 MAXIMUM CURRENT ADJUSTMENT
With the hand set is possible to modify the maximum current setting. In order to modify
it Enter the ALARM CONFIG MENU. Push at the same time the two right side buttons.
This sequence will enter the hidden ZAPI MENU. Roll up and down (buttons 1 and 2)
until the "HARDWARE SETTING" appears on the hand set display. Enter it and change
with the right side buttons the maximum current setting. Save the new setting before
exiting. Switch off and on the key to acquire the new setting. It is important that the new
maximum current value is compatible with the Eps_ac version you have.
