Zebra 105SL Installation Instruction

Media Rewind Upgrade
Preparing the Printer
4
33181L-001 Rev. A 10/23/2006
Preparing the Printer
Printer Configurations 10500-0XXX-XXXX and
10500-1XXX-XXXX.
The printer must be partially disassembled to install the various parts provided in this kit. Use
the following procedure to disassemble the printer.
1.
2.
3.
4.
Remove the two screws securing the electronics cover. Remove the cover.
Note • Retain all parts removed during disassembly, unless otherwise directed.
Caution • Observe proper electrostatic safety precautions when handling
static-sensitive components such as circuit boards and printheads.
Connect yourself to an antistatic device.
Caution • Turn off (O) the printer and disconnect it from the power source before
performing the following procedure.
Turn off (O) the printer and disconnect the AC power cord and all data cables.
Caution • While performing any tasks near an open printhead, remove all rings,
watches, hanging necklaces, identification badges, or other metallic objects that could
touch the printhead.
Open the right side media cover and remove all media and ribbon from the printer.
Note • You can leave all wires and cables attached to the DC power supply board. With
wires still attached, move the assembly aside to gain access to the area of the printer you
need to install the kit parts.

Zebra 105SL Specifications

General

Print technology	Direct thermal
Display	LCD
Product color	Gray
Network ready	Yes
Dimensions (WxDxH)	283 x 495 x 394 mm
Standard interfaces	Parallel, Serial
Internal memory	6 MB
Maximum label width	115 mm
Maximum label length	0.991 m
Power requirements	90-264 VAC, 48-63 Hz

Weight and Dimensions

Depth	495 mm
Width	283 mm
Height	394 mm
Weight	29000 g
