Zte MF65 Quick Start Guide

4 5
Indicators
Indicator Status Description
Network
Red solid
Error status. Not registered to the mobile net-
work, no (U)SIM card inserted or no network
service available.
Green solid Registered to the mobile network.
Green blinking
Connected to the mobile network and data is
being transferred.
Wi-Fi
Blue solid Wi-Fi is active.
Blue blinking WPS is active.
LED light off Wi-Fi is off or your device is in sleep mode.
Battery
Red solid/ blinking The battery is low. Please charge the battery.
Green blinking The battery is being charged.
Green solid The battery level is middle or high.
LED light off
Your device is in standby mode and not being
charged, or the battery is not inserted.
Connection Scenario
Your device supports two methods to connect to the Internet and supports multi-
clients for surng on the Internet at the same time. The following gure is only
for your reference.
• 3G Mode: Use your (U)SIM card to access the Internet.
• AP Station Mode: Your device will connect to other WLAN device (hotspot
device, wireless router, etc.) via Wi-Fi to access the Internet. The WLAN de-
vice has already connected to the Internet.
NOTE:
The subnets of your device and other WLAN device must be different.

Zte MF65 Specifications

General

Type	Mobile
Networking features	HSDPA/3G UMTS/GSM
DC-in jack	Yes
Internal	No
Number of WLAN connections (max)	5
Maximum data transfer rate	21.6 Mbit/s
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n

Weight and Dimensions

Weight	75 g
Dimensions (WxDxH)	50 x 13.7 x 102 mm
