Zte VS2801SG User Manual

1GE Dual Mode ONU User Manual
Optical interface
SC/PC connector
Interface
1* 10/100/1000Mbps auto adaptive Ethernet interfaces. Full /Half
Duplex, RJ45 connectors.
Indicator
3 indicators, SYS, LINK/ACT, REG.
Operating condition
-5℃～55℃，10%～90%（non-condenseing）
Storing condition
-30℃～60℃，10%～90%（non-condenseing）
Power supply
DC 12V, 0.5A
Power consumption
≤4W
Dimension
82mm×82mm×25mm（L×W×H）
Net weight
0.08Kg
1.4 Application chart
Figure 1-2: Application chart
1.5 Panel description
Interface/Button panel
