ZXV10 H100 Home Gateway User Manual (Draft)
1-2
WAN side:
ADSL interface: Built-in splitter, compatible with ADSL/ADSL2/2+
LAN side:
Fast Ethernet port: four, RJ-45, 10/100Mbps, complies with the IEEE802.3
and IEEEE802.3u standards
WLAN interface: Complies with the IEEE 802.11g/b standard, built-in antenna
Blue Tooth interface: Supports Core V1.2, built-in antenna
POTS interface: RJ11, 2-port
USB interface: 1 master (V2.0) & 1 slave (V1.1)
Extended interface (optional):
Card Bus: One, supports the 16-bit PCMCIA and 32-bit CARDBUS cards
• Technical Features
It implements two functions: data access and IP voice. The data exchange and
forwarding functions of Layer 2 and Layer 3 are implemented for data access
and the IP voice function is implemented according to different signaling
protocols and related network devices. In addition to providing the above
functions, the product gives much consideration to security, QOS and network
management, such as multi-level authentication based on devices, users and
services, encryption of data channels, implementation of QOS requirements
matching the local devices and network according to services with different
requirements, network management based on multiple management modes.
1.4 Appearance of the Product
The planform of the H100 is shown below:
