Page #22 background imageLoading...
Page #22 background image
22
Item Description DEL-30 DEL-40 DEL-50 DEN-30 DEN-40 DEN-52 DEN-66 DEN-80 DEN-120
Series 110 Series 110 Series 110 Series 110 Series 110 Series 110 Series 110 Series 110 Series 110
1A ....Anode, Alum. ............................ 9003944005 ....9003944005 ... 9003944005 ....9003944005 ...9003944005 ... 9003944005 ... 9000029005 .... 9003892005 ....9003892005
1B ....Anode, Mag.(SMR P72)............ 9003721005 ....9003721005 ... 9003721005 ....9003721005 ...9003721005 ... 9003721005 ... 9003721005 .... 9001829005 ....9001829005
2 .....T&P Relief Valve ........................ 9003741005 ....9003741005 ... 9003741005 ....9000071005 ...9000071005 ... 9000071005 ... 9000071005 .... 9000071005 ....9000071005
3 .....Gasket, Element ........................ 9000308045 ....9000308045 ... 9000308045 ....9000308045 ...9000308045 ... 9000308045 ... 9000308045 .... 9000308045 ....9000308045
4 .....ELEMENT, each ............................................................................................... (SEE ELEMENT & WATTAGE CHART page 23 ) .....................................................................
5 .....Upper Thermostat w/Hi Limit .... 9002856015 ....9002856015 ... 9002856015 ....9002856015 ...9002856015 ... 9002856015 ... 9002856015 .... 9002856015 ....9002856015
6 .....Lower Thermostat w/Hi Limit .... 9002857015 ....9002857015 ... 9002857015 ....9002857015 ...9002857015 ... 9002857015 ... 9002857015 .... 9002857015 ....9002857015
7 .....Thermostat Bracket, each ......... 9003898215 ....9003898215 ... 9003898215 ....9003898215 ...9003898215 ... 9003898215 ... 9003898215 .... 9003898215 ....9003898215
8 .....Personal Protector ..................... 9003914015 ....9003914015 ... 9003914015 ....9003914015 ...9003914015 ... 9003914015 ... 9003914015 .... 9003914015 ....9003914015
9 .....Lower Access Panel .................. 9003900005 ....9003900005 ... 9003900005 ....9003900005 ...9003900005 ... 9003900005 ... 9003900005 .... 9003900005 ....9003900005
10 ....Dip Tube..................................... 9003902005 ....9003902005 ... 9003902005 ....9003902005 ...9003903005 ... 9003904005 ... 9003905005 .... 9003905005 ....9005709205
11 ....Power Terminal .......................... 9005719215 ....9005719215 ... 9005719215 ....9005719215 ...9005719215 ... 9005719215 ... 9005719215 .... 9005719215 ....9005719215
12 ....Drain Valve ................................ 9003906015 ....9003906015 ... 9003906015 ....9003906015 ...9003906015 ... 9003906015 ... 9003906015 .... 9003906015 ....9003906015
15*....Junction Box Assembly ..................195171 ............195171............ 195171 ............195171 ............ 195171 ............195171 ............195171 .............195171 ............195171
16*....Manual ..........................................322055-0 ........ 322055-0 .........322055-0 ........ 322055-0 .........322055-0 .........322055-0 ........322055-0 .........322055-0 ........ 322055-0
*Not Illustrated.
Standard Hardware Items May Be Purchased Locally.
Underlined Parts Are Recommended For Emergency Replacement.
