Technical data 115
Quick guide for selecting between gG and aR fuses
The table below is a short cut in selecting between gG and aR fuses. The
combinations (cable size, cable length, transformer size and fuse type) in the table
fulfill the minimum requirements for the proper operation of the fuse.
ACS800-01
size
Cable type Supply transformer minimum apparent power S
N
(kVA)
Copper Aluminum Max. cable length with gG
fuses
Max. cable length with aR
fuses
10 m 50 m 100 m 10 m 100 m 200 m
Three-phase supply voltage 208 V, 220 V, 230 V or 240 V
-0025-2 3×25 Cu 3×35 Al 31 38 - 27 27 -
-0030-2 3×35 Cu 3×50 Al 44 55 - 33 33 -
-0040-2 3×50 Cu 3×70 Al 58 71 - 41 41 -
-0050-2 3×70 Cu 3×95 Al 72 87 - 55 70 -
-0060-2 3×95 Cu 3×120 Al 85 110 - 65 70 -
-0070-2 3×120 Cu
3×185 Al
1)
99 120 - 81 81 -
Three-phase supply voltage 380 V, 400 V or 415 V
-0040-3 3×25 Cu 3×35 Al 54 57 71 48 48 48
-0050-3 3×35 Cu 3×50 Al 76 82 110 58 58 58
-0060-3 3×50 Cu 3×70 Al 100 110 140 70 70 70
-0075-3 3×70 Cu
3×95 Al
2)
130 140 160 99 99 140
-0070-3 * 3×70 Cu 3×95 Al 130 140 160 96 96 140
-0100-3 3×95 Cu 3×120 Al 150 160 190 120 120 140
-0120-3 3×120 Cu
3×185 Al
1)
170 190 210 140 140 140
-0135-3 3×150 Cu
3×240 Al
3)
200 220 250 160 160 160
-0165-3 3×185 Cu
3×240 Al
3)
240 260 310 180 180 200
-0205-3 3×240 Cu 2×(3×95) Al 232 257 310 134 153 196
Three-phase supply voltage 380 V, 400 V, 415 V, 440 V, 460 V, 480 V or 500 V
-0050-5 3×25 Cu 3×35 Al 67 70 79 56 56 56
-0060-5 3×25 Cu 3×50 Al 95 110 130 68 68 68
-0070-5 3×35 Cu 3×70 Al 130 140 160 83 83 83
-0105-5 3×70 Cu
3×95 Al
2)
160 170 190 130 130 150
-0100-5 * 3×70 Cu 3×95 Al 160 170 190 110 120 150
-0120-5 3×95 Cu 3×120 Al 190 200 220 140 140 150
-0140-5 3×95 Cu 3×150 Al 190 200 220 160 160 160
-0165-5 3×150 Cu
3×240 Al
3)
250 260 290 200 200 200
-0205-5 3×185 Cu
3×240 Al
3)
290 320 360 230 230 230
-0255-5 3×240 Cu 2×(3×95) Al 289 312 355 167 185 218
1)
This cable type cannot be used in the drive because the lead-through in the drive is too small.
2)
This cable type cannot be used in the drive because the cable terminal is too small.
3)
This cable type cannot be used in the drive because the lead-through in the cable connection box is
too small (see
Dimensional drawings on page 133).
4)
This cable type cannot be used in the drive because the cable lug is not designed for multiple wires.
* Type not available any more.
