ABB ACS800-07 User Manual

Line options (F)
23
ACS800-17 and ACS800-37 frames R6, R7i and R8i
Standard features
The cabinet is equipped with a switch fuse type of main switch which contains ultra-
rapid semiconductor fuses (Class aR), and with a line contactor.
* optional in frame R6, standard in frames R7i and R8i
More information: Hardware manual
ACS800-17 and ACS800-37 frames n×R8i
Standard features
The cabinet is equipped with an air circuit breaker and aR fuses.
More information: Hardware manual
+F250 *
M
3~
Main switch
Drive
Control
+F255
U<
+F260
Supply
module
Drive
