Line options (F)
24
Line contactor (F250)
This option provides a line contactor with a manual operating switch on the cabinet
door.
ACS800-07/U7 frames R5 to R8
Standard for ACS800-17/37 frames R6, R7i and R8i.
Other required options: Emergency stop function +Q951 or Q952, see page 39.
More information: Hardware manual, ACS800 Safety Options Hardware Manual
(3AFE68578027[English]).
Frames n×R8i (ACS800-07)
This option provides a line contactor inside each supply module.
Other required options: Emergency stop function +Q951 or Q952, see page 39.
Not available for ACS800-17 and ACS800-37.
More information: Hardware manual, ACS800 Safety Options Hardware Manual
(3AFE68578027[English]).
gG line fuses (F251)
The option replaces the aR AC fuses with gG fuses. See the hardware manual in
which cases gG fuses are allowed.
Available only for ACS800-07 frames R5 to R8.
+F250
M
3~
Main switch
Drive
Control
Main switch
Supply module
Drive
+F250
Control
