6 Advance Optima Ex Analyzer Modules Operator’s Manual 42/24-12-2 EN
Chapter 1 Installation
Unpack and Install the Ex Analyzer Module
F
Follow
• the instructions and notes in the "Analyzer System Installation" chapter of
Operator’s Manual 42/24-10 EN,
• the following special instructions and notes as well as
• the notes in the "Electrical Equipment in Explosion Hazard Zones" sections in
the Annex.
CAUTION!
The Ex analyzer module weighs approx. 26 kg! The following points should be
observed:
• Two persons are needed for unpacking and installation.
• The installation location must be stable and in order to support the Ex
analyzer module’s weight.
Quantity Description
1 Ex analyzer module with attached connection cables for 24 VDC
power and system bus
1 Analyzer Data Sheet (in the central unit system housing)
1Operator’s Manual 42/24-10 EN
1Operator’s Manual 42/24-12 EN
1 2.5 mm Hex Wrench
1 220 mm diam. x 3 mm O-Ring
Items Delivered
1 Emitter Wrench (only on Uras 14-Ex analyzer module)
Installation Site The Ex analyzer module can be installed in Zone 1 and Zone 2 explosion hazard
areas (see the “Operating Specifications,” section, Page 30)
F
The Ex analyzer module should not be mounted outdoors.
Conditions Temperature Range
Operation in compliance with sample-measuring data
Caldos 15-Ex, Caldos 17-Ex, Magnos 106-Ex +5 to +50°C
Uras 14-Ex +5 to +45°C
Operation without jeopardizing explosion protection
Caldos 15-Ex, Caldos 17-Ex, Magnos 106-Ex –20 to +50°C
Uras 14-Ex –20 to +45°C
Ambient Temperature
Storage and shipping –25 to +65°C
Continued on next page
