ABB AX521 User Manual

Fig. 12: Example for connection output AOx
Fig. 13: Example for connection input DIx
Fig. 14: Example for connection output DOx
9.5 Cleaning
Cleaning instruction
Do not use cleaning agent for cleaning the device.
Use a damp cloth instead.
9.6 Certification
Example Analog
Output
Example Digital
Input
Example Digital
Output
CI541-DP
Certification
2019/11/15 3ADR024117M02xx, 11, en_US 77

ABB AX521 Specifications

General

Brand	ABB
Model	AX521
Category	I/O Systems
Language	English
