5.1 Setting the Output
About the output
The C13 meter has one output which can be used for three different purposes.
When one of the three options has been chosen for the output, the remaining two
options are automatically disabled.
• Alarm monitoring
The output is used for monitoring if an alarm has been triggered or not.
• Static level
The output is set as static, either as static on or static off.
• Pulse output
The output is set as a pulse output.
Output state
The Output state in the main menu indicates what function is activated. See table
below for the different functions that can be activated
Set output to
pulse output
To set the pulse output to be available for pulse measuring, perform the following
steps when located in the view menu.
Activated function Output on display Comment
Alarm on The alarm is set and has been trig-
gered.The pulse output exit is deacti-
vated.
Alarm off The alarm is set but has not been trig-
gered. The pulse output exit is deacti-
vated.
Output on There is always a continous signal on the
output.
Output off The output is closed for all traffic, both in-
bound and outbound.
Pulse out The output is activated with a frequency
based on measured energy. The alarm
function is deactivated.
Step Action Comment
1 When located in the view menu, use the long
press to get to the set menu.
-
2 Use the long press to get to the selection of func-
tions menu.
-
3 Toggle through the menu to get to the Pulse out
choice. Use the long press to choose Pulse out
( on the display).
The Pulse out choice in the
selection of function menu
is displayed as:
To Next Page
