Technical Description
C13 30 2CMC486004M0201
User Manual Revision: A
6.3 Outputs
About outputs
The C13 meter has one output which can be used for three different purposes.
When one of the three options has been choosen for the output, the remaining two
options are automatically disabled.
• Alarm monitoring
The output is used for monitoring if an alarm has been triggered or not.
• Static level
The output is set as static, either as static on or static off.
• Pulse output
The output is set as a pulse output.
On the pulse output the meter sends out a specified number of pulses (pulse fre-
quency) per kilowatt hour (kilovar for reactive pulse outputs). The amount of
pulses sent out are in proportion to the energy flowed through the meter.
The meter has a pulse output frequency of 100 imp/kWh and the pulse width is
200 ms.
