7.1 Technical Specifications
Specifications for C13 direct connected meter
Voltage/current inputs
Nominal voltage 3x230/400 VAC
Voltage range 3x220–240 VAC (-20% – +15%)
Power dissipation voltage circuits 1.5 VA (0.6 W) total
Power dissipation current circuits 0.04 VA (0.04 W) per phase at 230 VAC and I
b
Base current I
b
5 A
Reference current I
ref
5 A
Transitional current I
tr
0.5 A
Maximum current I
max
40 A
Minimum current I
min
0.25 A
Starting current I
st
< 20 mA
Terminal wire area 0.5–10 mm
2
Recommended tightening torque 0.8 Nm
General data
Frequency 50 or 60 Hz ± 5%
Accuracy 1% (Cl. 1, Cl. B)
Display of energy 7-digit LCD
Mechanical
Material Polycarbonate in transparent front glass. Glass reinforced
polycarbonate in bottom case and upper case. Polycarbonate
in terminal cover.
Weight 190 g
Environmental
Operating temperature -25°C – +70°C
Storage temperature -25°C – +85°C
Humidity 75% yearly average, 95% on 30 days/year.
Resistance to fire and heat Terminal 960°C, cover 650°C (IEC 60695-2-1)
Pulse output
Current 2–100 mA
Voltage 5–40 VDC
Pulse output frequency 100 imp/kWh
Pulse length 200 ms
Terminal wire area 0.5–6 mm
2
Recommended tightening torque 0.8 Nm
Pulse indicator(LED)
Pulse frequency 1000 imp/kWh
Pulse length 40 ms
EMC compatibility
