2CMC486004M0201 31 C13
Revision: A User Manual
Technical Description
6.4 Alarm
General
The purpose of the alarm function is to enable monitoring of quantities in the
meter. Monitoring can be set to high or low level detection. High level detection
gives an alarm when the level of a quantity goes above the set level. Low level
detection gives an alarm when the value goes below the set level.
Quantities
Depending on the meter type all or a subset of the following quantities can be
monitored:
• Active power
• Power factor
• Current L
• Voltage L-N
Functional
description
When the value of the monitored quantity passes the activation level, and remains
there for a period of time equal or longer than the specified time delay, the alarm
is activated. In the same way, the alarm is deactivated when the value passes the
deactivation level and remains there for a time equal to or longer than the speci-
fied time delay.
If the activation level is higher than the deactivation level, the alarm is activated
when the value of the monitored quantity is higher than the activation level.
If the activation level is lower than the deactivation level, the alarm is activated
when the vale of the monitored quantity is lower than the activation level.
