CP1484, CP1485, CP1486, CP3484, CP3485, CP3486
Data sheet V 1.00
Connection examples
With two separate supplies
With a supply and jumper
Figure 5: X20 CPUs - connection example with two separate supplies
Figure 6: X20 CPUs - connection example with a supply and jumper
PS
GND
+24 VDC
+
_
I/O
supply
CP/X2X Link
supply
+
_
PS
GND
+24 VDC
+
_
I/O
supply
Jumper
