CP1484, CP1485, CP1486, CP3484, CP3485, CP3486
Data sheet V 1.00
1) Modules CP1486 and CP3486 have exchangeable fan
Model number Short description
X20CP3484 X20 CPU, Celeron 266 comp., 32 MB DRAM, 1 MB SRAM, exchangeable application memory:
CompactFlash, 3 insert slots for X20IF modules, 2 USB interfaces, 1 RS232 interface, 1 Ethernet
interface 10/100 Base-T, 1 ETHERNET Powerlink interface, order program memory separately.
X20CP3485 X20 CPU, Celeron 400, 32 MB DRAM, 1 MB SRAM, exchangeable application memory:
CompactFlash, 3 insert slots for X20IF modules, 2 USB interfaces, 1 RS232 interface, 1 Ethernet
interface 10/100 Base-T, 1 ETHERNET Powerlink interface, order program memory separately.
X20CP3486 X20 CPU, Celeron 650, 64 MB DRAM, 1 MB SRAM, exchangeable application memory:
CompactFlash, 3 insert slots for X20IF modules, 2 USB interfaces, 1 RS232 interface, 1 Ethernet
interface 10/100 Base-T, 1 ETHERNET Powerlink interface, order program memory separately.
Program memory
5CFCRD.0064-03 CompactFlash 64 MB TrueIDE SSI
5CFCRD.0128-03 CompactFlash 128 MB TrueIDE SSI
5CFCRD.0256-03 CompactFlash 256 MB TrueIDE SSI
5CFCRD.0512-03 CompactFlash 512 MB TrueIDE SSI
5CFCRD.1024-03 CompactFlash 1024 MB TrueIDE SSI
5CFCRD.2048-03 CompactFlash 2048 MB TrueIDE SSI
5CFCRD.4096-03 CompactFlash 4096 MB TrueIDE SSI
Included in delivery
4A0006.00-000 Backup battery (see also section 1.1.18 "Changing the lithium battery" on page 20)
- Interface module slot covers
X20AC0SR1 X20 locking plate (right)
X20TB12 Standard X20 terminal block (12-pin)
Table 1: X20 CPUs - order data
