ABB CP600 Series User Manual

CONTROL PANELS CP600 2ND GENERATION
CP600 2nd generation, 2, en_US 11
6 Technical data
Model
CP6407
CP6410
CP6415
Display
TFT Color / LED
TFT Color / LED
TFT Color / LED
Colors
64K
64K
64K
Resolution
800X480
800X600
1024X768
Diagonal
7” widescreen
10.4”
15”
Dimming
yes
yes
yes
Flash
4GB
4GB
4GB
SD card slot
yes
yes
yes
RAM
512MB
512MB
512MB
Serial port
RS
-232,RS-485, RS-422
software configurable
RS
-232,RS-485, RS-422
software configurable
RS
-232,RS-485, RS-422
software configurable
Ethernet port
2 10/100Mb
2 10/100Mb
2 10/100Mb
USB port
2 Host interface ver-
sion 2.0
1 max. 100mA, 1 max.
500mA
2 Host interface ver-
sion 2.0
1 max. 100mA, 1 max.
500mA
2 Host interface ver-
sion 2.0
1 max. 100mA, 1 max.
500mA
Battery
rechargeable
rechargeable
rechargeable
RTC
yes
yes
yes
Voltage
24Vdc (*)
24Vdc (*)
24Vdc (*)
Current rating
at 24Vdc
0.35A
0.40A
0.70A
Weight
1.0 Kg
2.0 Kg
3.5 Kg
* 10-32Vdc
For applications requiring compliance with EN 61131-2 and specifically in reference to 10 ms
voltage dips, the power supply range voltage is 18-32Vdc.
