ABB CP600 Series User Manual

CONTROL PANELS CP600 2ND GENERATION
CP600 2nd generation, 2, en_US 9
5 Technical specifications
Touchscreen technology
Resistive
Back
-up battery
3 V 50 mAh Lithium, rechargeable, not user-replaceable,
model VL2330
.
Fuse
Automatic
Serial port
RS-232, RS-485, RS-422 software configurable
Flash
4 GB
RAM
512 MB
Hardware clock
Clock/Calendar with back-up battery
Accuracy RTC (at 25°C)
< 100 ppm
Environmental conditions
Operating temperature
-20 … +60 °C (vertical installation)
EN 60068-2-14
Storage temperature
-
20 … +70 °C
EN 60068
-2-1
EN 60068
-2-2
EN 60068-2-14
Operating and storage
humidity
5 …
85 % RH not-condensing
EN 60068
-2-30
Vibrations
5 … 9 Hz, 7 mm; 9 … 150 Hz, 1 g
p-p
EN 60068-2-6
Shock
± 50 g, 11 ms, 3 pulses per axis
EN 60068-2-27
Protection class
Front panel IP66, Rear IP20
EN 60529
Electromagnetic Compatibility (EMC)
Electrostatic discharge
immunity test
8 kV (air
electrostatic discharge)
4 kV (contact electrostatic discharge)
EN 61000
-4-2
Radiated, radio
-frequency,
electromagnetic field
immunity test
80 MHz … 1 GHz, 10
V/m
1
.4 GHz … 2 GHz, 3 V/m
2 GHz … 2.7 GHz, 1 V/m
EN 61000
-4-3
Burst immunity test
±
2 kV DC power port
±1 kV signal line
EN 61000
-4-4
Surge immunity test
±
0,5 kV DC power port (line to earth)
± 1 KV dc power port (line to line)
±1 kV signal line (line to earth)
EN 61000
-4-5
Immunity to conducted
disturbances inducted by
radiofrequency field
0.15…
80 MHz, 10 V
EN 61000
-4-6
Power frequency magnetic
field immunity test
Enclosure, 50
Hz, 30 A/m
EN 61000
-4-8
