ABB DSQC 688 User Manual

Modular PROFINET deviceA
Modules for the modular stationB
Ethernet switchC
PROFINET anybus device, DSQC 688D
IRC5 controllerE
PLCF
Specification overview
SpecificationItem
PROFINETIndustrial network
PROFINET version 2.0Specification revision
100 MbitData rate
Maximum 128 input bytes and 128 output bytes.Connection size
0x10CVendor ID
0x07Device ID
Configuration program
An external PROFINET configuration tool such as Step 7 from Siemens, together
with RobotStudio, is needed for the configuration of DSQC 688. The external
PROFINET configuration tool should be used according to the manual for the
program.
Application manual - PROFINET Anybus Device 17
3HAC050968-001 Revision: C
© Copyright 2008-2016 ABB. All rights reserved.
1 Introduction
1.2 The PROFINET anybus device for IRC5
Continued
