Mechanical installation
Contents of this chapter
This chapter contains a delivery checklist and instructions on how to install the extension
adapter.
Examining the delivery
The package contains:
• FEA-03 F-series extension adapter
• fastening screws and latches for DIN rail installation
• support bracket for vertical DIN rail installation
• this document.
Installing the extension adapter
The housing of the extension adapter has two spring-loaded latches for vertical or horizontal
35 x 7.5 mm DIN rail installation. Install the DIN rail on a correctly grounded base. If this is
not possible, use a separate grounding conductor. Keep the grounding conductor as short
as possible. The cross-sectional area must be at least 6 mm
2
.
WARNING!
Install the adapter so that air can pass freely through the ventilation holes in the
housing. Do not install the adapter directly above heat generating equipment.
4
Mechanical installation 15
10
