Diagnostics
Contents of this chapter
This chapter explains how to trace faults with the status LEDs on the extension adapter.
General
See the applicable drive firmware manual for fault and warning messages.
Diagnostic LEDs
DescriptionColorLED
Is lit when power applied to the extension adapter is
OK.
GreenPWR OK
Is lit when the initialization of the option module con-
nected to Slot 1 is OK.
GreenSLOT 1 STATUS
Is lit when the initialization of the option module con-
nected to Slot 2 is OK.
GreenSLOT 2 STATUS
7
Diagnostics 25
