5 Positioner interface IRBP C
IRBP C
xx0900000846
I/O board configuration for positioner
Relay out-
puts
Analog
outputs
Digital in-
puts
Digital
outputs
Digital in-
puts
Board
type
NameAddress
Simulated
digital I/O
B_POS_SIM-
---127Digital I/O
DRVIO_1
i
Internal
bus
i
The number relates to the drive module where the I/O board is located, the example shows drive
module 1.
Simulated outputs and inputs for B_POS_SIM
Simulated outputs
DescriptionNameDeviceMap
Activate mechanical unit 1soACT_STN10
Simulated inputs
DescriptionNameDeviceMap
Mechanical unit 1 activatedsiSTN1_ACT0
Continues on next page
Application manual - Signal description for arc welding products 27
3HAC050975-001 Revision: -
© Copyright 2004-2016 ABB. All rights reserved.
5 Positioner interface IRBP C
