Navigator 600 Series Analyzers
Silica and Phosphate Appendix A – GSD File Module
6 IM/NAV6PBS Issue 1
Appendix A – GSD File Module
A.1 Module 01
Table A.1 defines the Module 01 data available from a Navigator
600 Series analyzer via Profibus cyclic transfer:
A.2 Status Byte Definition
Table A.2 defines the meaning of the contents of a Navigator
600 Series analyzer's status byte.
Note.
 Float = Floating-point number – requires 4 bytes
 Char = Character – requires 1 byte
 Int = Integer – requires 2 bytes
Byte Typ e Description
1 to 4 Float Stream 1 value
5 Char Stream 1 status
6 to 9 Float Stream 2 value
10 Char Stream 2 status
11 to 14 Float Stream 3 value
15 Char Stream 3 status
16 to 19 Float Stream 4 value
20 Char Stream 4 status
21 to 24 Float Stream 5 value
25 Char Stream 5 status
26 to 29 Float Stream 6 value
30 Char Stream 6 status
Table A.1 Module 01 Data
Byte (Hex) Definition
1C OOS (Out of Service)
80 Good
89 Low alarm limit advisory alarm
8A High alarm limit advisory alarm
8D Low-low alarm limit critical alarm
8E High-high alarm limit critical alarm
Table A.2 Status Byte Definition
