Navigator 600 Series Analyzers
Silica and Phosphate Appendix B – Acyclic Parameter Mapping
IM/NAV6PBS Issue 1 7
Appendix B – Acyclic Parameter Mapping
1
Store Definitions:
2
Access Definitions:
C = Constant – the value held in a Navigator 600 Series analyzer does not change R – Read only.
D = Dynamic – a value or state calculated by a Navigator 600 Series analyzer R/W – Read/Write.
N = Non-volatile – typically a configuration parameter that is stored in a Navigator 600 Series analyzer's non-volatile memory
Description Slot
Slot
Index
Object
Typ e
Data Type Bytes Store
1
Access
2
Default Valid Range Note
Physical Block Parameters
Software revision 0 24 Simple VisibleString 16 C R Current revision ASCII string Low level version number
Hardware revision 0 25 Simple VisibleString 16 C R Current revision ASCII string
Manufacturer identification 0 26 Simple Unsigned16 2 C R 26 (ABB)
Device identification 0 27 Simple VisibleString 16 C R AW641 SiO2
AW641 – SiO2
AW642 – PO4
AW642 – P
Device serial number 0 28 Simple VisibleString 16 C R
Unit's serial
number
ASCII string
Device diagnosis information 0 29 Simple OctetString 4 D R See Table B.2, page 45
Additional device diagnosis
information
0 30 Simple OctetString 6 D R
Navigator 600 specific errors
See Table B.2, page 45
Diagnosis definition 0 31 Simple OctetString 4 C R See Table B.2, page 45
Extended diagnosis definition 0 32 Simple OctetString 6 C R See Table B.2, page 45
Device certification 0 33 Simple VisibleString 32 C R
Number of streams fitted 0 64 Simple Unsigned8 1 N R 1 to 6
Instrument tag 0 65 Simple VisibleString 20 N R/W Navigator 600 ASCII string
HMI software revision 0 66 Simple VisibleString 16 C R Current revision ASCII string
OS software revision 0 67 Simple VisibleString 16 C R Current revision ASCII string
Instrument type 0 68 Simple Unsigned8 1 C R 0
0 = Silica
1 = Phosphate
Table B.1 Data Structure (Sheet 1 of 38)
