AC500-eCo - 25 - Hardware Introduction
4.2 Order Number
CPUs
Type
Program
memory
Cycle time in ms 1000
instructions
Bit/Word/Float. Point
Onboard
I/Os
DI/DO/AI/AO
Power supply Order Number
PM554-T 128 KB 0.3 / 0.3 / 6 8 / 6 / – / – 24 V DC 1TNE968900R0100
PM554-R 128 KB 0.3 / 0.3 / 6 8 / 6 / – / – 24 V DC 1TNE968900R0200
PM554-R-AC 128 KB 0.3 / 0.3 / 6 8 / 6 / – / – 100-240V AC 1TNE968900R0220
PM564-T * 128 KB 0.3 / 0.3 / 6 6 / 6 / 2 / 1 24 V DC 1TNE968900R1100
PM564-R * 128 KB 0.3 / 0.3 / 6 6 / 6 / 2 / 1 24 V DC 1TNE968900R1200
*All analog inputs on AC500 CPU PM564 can be configured as digital inputs.
The I/O modules
Type
DI/ DO/ DC
Inputs-signal Outputs-
type
Outputs-signal Order Number
DI561 8 / – / – 24 V DC – – 1TNE968902R2101
DI562 16 / – / – 24 V DC – – 1TNE968902R2102
DI571 8 / – / – 100-240 V AC – – 1TNE968902R2103
DO561 – / 8 / – 24 V DC Transistor 24 V DC, 0,5 A 1TNE968902R2201
DO571 – / 8 / – – Relay
24 V DC, 120/240 V
AC, 2A
1TNE968902R2202
DO572 – / 8 / – – Triac 100-240 V AC, 0,3A 1TNE968902R2203
DX561 8 / 8/ – 24 V DC Transistor 24 V DC, 0,5 A 1TNE968902R2301
DX571 8 / 8 / – 24 V DC Relay
24 V DC, 120/240V
AC, 0,5 A
1TNE968902R2302
DC561 – / – / 16 24 V DC Transistor 24 V DC, 0.1A 1TNE968902R2001
AI561 4 / 0
-2.5...+2.5 V, -5...+5 V, 0...5 V,
0...10 V, 0...20 mA, 4...20 mA
– 1TNE968902R1101
AO561 0 / 2 –
-10...+10 V, 0...20
mA, 4...20 mA
1TNE968902R1201
AX561 4 / 2
-2.5...+2.5 V, -5...+5 V, 0...5 V,
0...10 V, 0...20 mA, 4...20 mA
-10...+10 V, 0...20
mA, 4...20 mA
1TNE968902R1301
AI562 2 / 0
PT100, PT1000, Ni100,
Ni1000, Resistance: 150Ω,
300Ω
– 1TNE968902R1102
AI563 4 / 0
S, T, R, E, N, K, J, Voltage
range : ±80 mV
– 1TNE968902R1103
The Starter-Kit
Type Description Order Number
Starter-Kit CPU: PM554-R, AC, TK503 programming cable, PS501
Control Builder software for Starter-Kit
