1SFC132374M0201 16
4.2 Digital Output Telegram
To write the digital output telegram, use Modbus function code 5 Write Single Coil or 15 (0Fh)
Force Multiple Coils. To read the digital output telegram, use Modbus function code 1 Read Coil
Status or 2 Read Input Status.
Address for data access to device connected to port
Commence a stop when
this coil is set (this coil has
higher priority than the
start coil). The stop coil is
only acknowledged if the
Auto mode coil is set.
Commence a start when
this coil is set. The start
coil is only acknowledged
if the Auto mode coil is
set.
This coil must be set for
controlling the motor.
Reset an active fault or
protection when this coil is
set.
Clear active diagnostics
when this coil is set
