ABB PST72 Installation And Maintenance Manual

PST B 370-600 -70
] ] ] ]
]
3:4 Type designation
Control Voltage
70 = 100 - 250V 50/60 Hz
Main Voltage
600 = 208 - 600V 50/60 Hz
690 = 400 - 690V 50/60 Hz
Current Rating
600 = 208 - 600V 50/60 Hz
690 = 400 - 690V 50/60 Hz
Bypass contactor
600 = 208 - 600V 50/60 Hz
690 = 400 - 690V 50/60 Hz
Softstarter type
3:4 Industrial
IT
Thanks to ABB’s broad program of product standardisation, today’s Industrial IT components are - whether they are products or systems, hardware or
software - the building blocks of larger solutions, incorporating functionalities that will allow seamless interactions in real-time automation and informa-
tion systems.
At the product level, ABB’s Industrial IT enabled symbol ensures that all the products can fully interact. All product information pertaining to these
products is available in electronic format, based on Aspect Object
TM
technology. The Industrial IT commitment from ABB ensures that every product is
equipped with the tools necessary to install, operate and maintain it efciently throughout the product’s life cycle.
The PST softstarters is an Industrial IT enabled product. Documentation such as brochures, catalogues, certicates and drawings can be found at :
www.abb-control.com/products/softstarters.htm#type_pst.
3:6 Environmental inuence
The product is designed to minimize the environmental affects during manufacturing and use of the product. Most of the materials used are recyclable.
3:7 Specications
Item Specication
Degree of protection (main circuit) IP 10 for PST30...72; IP 00 for PST85...1050
Operating position Vertical at ± 10°
Ambient temperature Storage: -25°C to +70°C (-13°C to 158°F)
Operation
Without derating
With derating
0°C to +40°C (32°F to 104°F)
+40° C to +50°C (104°F to 122°F) of 0.8% / °C (1.8%/°F)
Altitude 1000 m (3281 ft.) above sea level without derating
1000 - 4000 m (3281 - 13,123 ft.) by derating 1% for each 333 ft above 3300 ft.
Pollution degree 3
Relative humidity 5 - 95% (non-condensing)
Standards UL508
IEC 60947-1
IEC 60947-4-2
EN 60947--1
PTC input IEC 60947-8 Mark A detectors, DIN 44081 and DIN 44082
Marine approvals Contact your ABB sales ofce
Chapter 3 - Description
3.4 Low Voltage Products & Systems
1SXU 132 021 M0201 ABB Inc. • 888-385-1221 • www.abb-control.com
3
