7:2 Description of menus
For detailed description of each function, see Chapter 10 “ Functions” .
7:2.1 Top level
This level contains information about output voltage, current, heat sink temperature, real time clock
and more. From this menu, the keypad can be locked/unlocked and a password can be set. It is
also possible to enter all top level menus.
Display at start up
When switching on the control voltage, the LCD will rst display the text “Hello”, and after a few
seconds switch to the Top Level start position, Figure 2.
Real time clock
The real time clock displays the present date and time. To set date, time and display types, see
“Presentation Settings.”
U
in
status
The softstarter checks and displays the status of the input voltage (line side).
Motor temperature
The consumed thermal capacity of the motor is displayed. 0% means that the motor is in cold state.
50% means that half the capacity is consumed, etc.
Status of inputs/outputs
The status of the Programmable inputs and outputs is displayed with “0” for not activated or “1” for
activated. The gures have the following functions:
In=0100 Start signal high
In=1000 Stop signal high
In=0010 In0 high
In=0001 In1 high
Out=1000 Relay K4 activated
Out=0100 Relay K5 activated
Out=0010 Relay K6 activated
Out=0001 SW V7 activated
SCR Temperature
The temperature of the SCRs in the softstarter is displayed as a percentage of the maximum value.
Keypad status
Information on whether the keypad is locked or unlocked. How to operate, see Chapter 6 “Human-
Machine Interface (HMI)”.
Change Password
Menu for changing the password, How to operate, see Chapter 6 “Human-Machine Interface (HMI)”.
Figure 1: Top level display loop
U=†††0% †I=0.0A
Menu
Change Password
Select Back
Keypad is Active
Lock Back
2003-01-30 11:08
Back
In=0000 Out = 0000
Back
Uin † OK
Back
Motor Temp 0%
Back
SCR Temp 60%
Back
Figure 2: Top level (start position)
5 )!
-ENU
Figure 3: Real time clock
2003-02-05 10:33
Back
Figure 4: U
in
status
Uin OK
Back
Figure 5: Motor temperature
Motor Temp 0%
Back
Figure 6: Input/outputs
In = 0000 Out = 0000
Back
Figure 7: SCR temperature
SCR Temp 60%
Back
Figure 8: Keypad status
Keypad is Active
Back
Figure 9: Change Password
Change Password
Select Back
Chapter 7
Settings and conguration
