ABB PSTX370 Service Manual

12 Description | Service Manual | 1SFC13105M0201
• PSTX210...370
• PSTX470...570
2.1.6 Dimension prints PSTX210...370, PSTX470...570
260 mm (10,2 in)
279.1 mm (10,9 in)
470 mm (18,5 in)
451.2 mm (17,7 in)
10,5 mm (0,4 in)
389 mm (15,3 in)
5 mm (0,2 in)151 mm (5,9 in)
Ø18 (2x)
200 mm (7,9 in)
258 mm (10,2 in)
43,7 mm (1,7 in) 4x
19,6 mm (0,8 in) 6x
1SFC132095M0201
361 mm (14.2 in)
282.15 mm (11.1 in)
262.82 mm (10.3 in)
6 mm (0.2 in) 6x
58.2 mm (2.3 in) 6x
25 mm (0.9 in) 6x
336 mm (13.2 in) 2x
460 mm (18.1 in)
63 mm (2.5 in) 4x
493 mm (19.4 in) 466 mm (18.3 in)
9 mm (0.3 in)
7 mm (0.2 in) 4x
Ø13 (4x)
1SFC132095M0201
2

ABB PSTX370 Specifications

General

Brand	ABB
Model	PSTX370
Category	Controller
Language	English
