4.5 Generic REB500 functions
4.5.1 Diagnostic information
GUID-9430347F-A35F-4AB3-A63A-9FF711FEBCB5 v2
Status and diagnostic information is generated by the various REB500 application software
modules and transferred spontaneously as events every time the status changes. A separate
group exists for diagnostic information with an entry for every subsystem of the REB500
system software REBSYS.
Diagnostic event group:
Table 15: Diagnostic event
ENTRY No. Group 64 (0x40)
0 (Heading) Diagnostic information
1 BBP (Busbar protection)
2 ITT (Intertripping)
3 BCF (Binary input and output configuration facility)
4 DIA (Diagnostic)
5 TGR (Test generator)
6 EMI (External man/machine interface)
7 LMI (Local man/machine interface)
8 DAC (Data access)
9 TIM (Time management)
10 DBS (Database system)
11 SIG (Signal processor)
12 EVR (Event recording)
13 RFS (Remote file system)
14 SPR (Signal pre-processing and recording)
15 MBA (Multi-function bus administrator)
16 OCP (Overcurrent protection)
17 BFP (Breaker failure protection)
18 DRR (Disturbance recorder)
19 MPL (Multi functional process bus library)
20 EFP (End-fault protection)
21 PDF (Pole discrepancy function)
22 BOC (Binary input/output control)
23 BPP (Binary pre-processing)
24 DIE (Diagnostic extensions)
25 DRD (Disturbance recorder dispatcher)
26 EVA (Event and alarm handling)
27 GPI (General purpose interface)
28 LAC (LON application converter)
29 IAC (IAC application converter)
30 CMD (Command processor)
Table continues on next page
1MRK 511 451-UEN B Section 4
IEC60870-5-103
Distributed busbar protection REB500 19
Communication protocol manual IEC60870-5-103
© Copyright 2019 ABB. All rights reserved
