01 H Entry <1 .. 32>
Current value <1> Kind of description
KOD
DATA STRUCTURE
<23>
21
1,0
DATA TYPE
DATA SIZE
NUMBER, CONT
GDD
<12> MEASUREMENT WITH QUALITY
DESCRIPTOR
2
3,0
DATA TYPE
DATA SIZE
NUMBER, CONT
GDD 1
3 or 4 (including measurement
L0)
OV ER RES MVAL (4 .. 8)
GID 1a
MVAL (9 .. 16)
OV ER RES MVAL (4 .. 8)
GID 1b
MVAL (9 .. 16)
OV ER RES MVAL (4 .. 8)
GID 1 c
MVAL (9 .. 16)
<14>
BINARY TIME
7
1,0
DATA TYPE
DATA SIZE
NUMBER, CONT
GDD 2
Time stamp (CP56Time2a)
GID 2
4.6 Special information and instructions for configuring
the control system
GUID-A8AF440A-22B6-4443-B341-64B408B162ED v2
Private range
Provision is made in the event configuration (see Section 3.3) for the user to enter his own
private IEC60870-5-103 definition for each REB500 signal.
The input fields for REB500 signals covered by the public part of the standard (see
Section 4.2)
have a bright yellow background their default setting
0
for both IEC function type and
information number. All other signals receive the presetting
0
for the IEC function type and the
information number. A signal defined for protocol 60870-5-103 that is not in the public range
and has
0
set for function type and information number is transmitted via the generic part of
the protocol.
A private IEC60870-5-103 definition can be entered for every REB500 signal in this dialog. The
Set Default button is enabled for a signal in the public range of the protocol so that the ABB
default setting can be restored at any time.
The limitations specified in the standard must be observed when assigning information
numbers. The latter must be within the following ranges:
16-52; 73; 128-130; 64-72; 74-93
Section 4 1MRK 511 451-UEN B
IEC60870-5-103
26 Distributed busbar protection REB500
Communication protocol manual IEC60870-5-103
