ABB REF 54 Series User Manual

1MRS 750500-MUM
)HHGHU7HUPLQDODQG0DFKLQH7HUPLQDO
Operator’s Manual
5(BB
27
 6HOIVXSHUYLVLRQ,5)
The RE_ 54_ terminal is provided with an extensive self-supervision system. The
system handles run-time fault situations in RE_ 54_ and informs the user about an
existing fault via the HMI and LON®
1
/SPA communication.
The green Ready LED indicator starts blinking when a fault has been detected. At
the same time, the terminal delivers a fault signal to the self-supervision output relay
of RE_ 54_. Additionally, a fault indication text appears on the HMI and an event
E57 is generated to serial communication (channel 0).
The fault indication text on the HMI consists of two constant rows as shown below.
Fault indication has the highest priority on the HMI. Other HMI indications cannot
overrun the IRF indication. When the display panel has received a fault indication,
the fault indication text remains on the HMI. The fault indication text can be cleared
from the display by pressing [C] for 2 seconds, but the green LED indicator remains
blinking. Blinking of the green Ready LED indicator cannot be stopped.
In case an internal fault disappears, the fault indication text stays on the display
unless it has been cleared by pressing [C]. The green Ready LED indicator stops
blinking and an alarm output IRF is released to normal service state. Moreover, an
event E56 is generated to serial communication (channel 0).
)DXOWFRGH
When an internal fault appears in RE_ 54_, the self-supervision system generates an
IRF code that indicates the type of the fault. The fault code can be read from MAIN
MENU/Status/General/IRF code. The code indicates the first internal fault
detected by the self-supervision system.
Do not reset the terminal before reading the IRF code. The code should be
noted and reported when overhaul is ordered.
 &RQGLWLRQPRQLWRULQJLQGLFDWLRQ
If the terminal includes condition monitoring functions that are not directly related
to any protection functions of the terminal or to the internal condition of the
terminal, they are indicated in the assisting window by the message SUPERV and
an explanatory text, see the example below.
1. LON is a trademark of Echelon Corporation registered in the United States and other
countries
assisupv
SELF SUPERVISION
*INTERNAL FAULT*
!
assisupi
CMTCS1:SUPERV
Trip circuit sup
