ABB REJ601 User Manual

1MDU07212-YN Rev. C Section 6
Installation
REF601 / REJ601 63
Application Manual
6.7 Relay ordering information
The relay type and serial number label identifies the protection relay. An order
number label is placed on the side of the relay. The order number consists of a
string of codes generated from the hardware and software modules of the relay.
The serial number and order number label is placed on side of relay.
Example code
REF601 B E4 46 B D 1 N H
#
Description
1
Relay type
Feeder protection with control
REF601
Feeder protection
REJ601
2
Standard
ANSI
A
IEC
B
Chinese
C
CEI
J
3,4
Analog input / output
3 sensor and ground current input A4
Phase and Earth current input – 1A D4
Phase and Earth current input – 5A E4
5,6
Binary input / output
4 BI + 6 BO
46
7
Serial communication
MODBUS RTU with RS485 two wire B
IEC60870-5-103 with RS485 two wire C
None N
8
Application configuration
Configuration 2 B
Configuration 3 C
Configuration 4 D
9
Power supply
24...240V AC / DC 1
10
Configuration
Ring lug terminals B
Screw terminals N
11
Version
Product version 2.2 FP1 H
Digit (#)
1
2
3,4
5,6
7
8
9
10
11
Your Order Code
Figure 33: Ordering information of relay REF601/REJ601
