ABB REJ601 User Manual

Section 6 1MDU07212-YN Rev. C
Installation
66 REF601 / REJ601
Application Manual
Table 29: Settings, continue
Parameter
Actual
value
Default
value
Unit Range Resolution
3Ith> / 49
ϑ0
080 % 0.0…100% 1%
ϑpowerOFF
4 - 1…4 1
Ib 1.0 In 0.1 … 1.5 0.100
τ↑
045 min 1.0…300 1.000
τ↓s
045 min 1.0…300 1.000
ϑalm
121 % 50…200%, 1%
ϑtrip
144 % 50…200%, 1%
ϑstartinhibit
105 % 50…200%, 1%
3I/IoBF / 51BF/51NBF
Icbfp 01.1 In 0.2…2.0 0.100
Iocbfp 01.1 In 0.1…2.0 0.100
t Retrip 0.10 s 0.06…0.5 0.010
t Backup 0.12 s 0.06…0.5 0.010
O -> I / 79
AR start
mode
1
-
1 = Trip, 2 = Gen. start and trip 1
CB ready 1
-
1 = OCO, 2 = CO 1
Shot 3
-
0…4 1
Activate t sec 0.1…5 0.100
Pulse tp sec 0.2…20 0.100
Cycle t1 sec 0.2…300 0.010
Cycle t2 sec 0.2…300 0.010
Cycle t3 sec 0.2…300 0.010
Cycle t4 sec 0.2…300 0.010
Reclaim tr sec 1…300 1
Block tb sec 1…300 1

ABB REJ601 Specifications

General

Rated Frequency	50/60 Hz
Communication Protocol	IEC 61850, Modbus RTU
Rated Current	1/5 A
Operating Time	<35 ms
Reset Time	<35 ms
Communication	Ethernet, RS-485
Protection Degree	IP20
