ABB | SACE Tmax XT
Settings | 1 - Main settings117 | © 2019 ABB | 1SDH002039A1002 - ECN000093027 - Rev. A
View
The View menu provides various options:
Parameter Description Default
TFT orientation
Enables the orientation of the Alarms List, Measuring Instruments and
Main Measurements pages to be set. The options are: Horizontal, Vertical
clockwise, Vertical counter-clockwise
Horizontal
Customer page
Allows you to activate a supplementary information page, which can
be accessed by pressing the iTEST button twice from any page with a
diagnosis bar. The information on the new page can be configured via Ekip
Connect (page 119)
Off
Ammeter Phase
Allows the current to be displayed in the Measuring instruments page to be
set from among the following options: Imax, I1, I2, I3, Ne (only in the 4P or
3P + N configuration)
Imax
Voltmeter Phase
Allows the voltage to be displayed in the Measuring instruments page to be
set from among the following options: Vmax, V12, V23, V31
Vmax
Maintenance
The parameter allows an alarm, concerning maintenance of the unit, to be enabled/disabled. (page 100).
Ekip Touch is supplied with the parameter set to: On.
MLRIU
The MLRIU parameters are available with Ekip M Touch for the Motor Protections functions (page 68).
NOTE: to ensure correct operation, check where applicable: presence and status of the
outgoing connections, those towards the Trip unit of Ekip CI and the relative output contact
(O61)
Parameters
Parameter Description Default
Open Mode
Allows the TRIP mode to be set (page 38):
• Heavy: in the event of a TRIP, it is controlled by the Trip coil of the CB
• Normal: contact O61 of the Ekip CI module is opened in the event of a
TRIP
NOTES:
• the TRIP for protections G or I always involves the Trip coil
command, regardless of the Open Mode configuration
• in the Normal mode, if the Trip unit detects the presence of a fault
even after the open command sent to O61, a command is also sent to
the Trip coil of the CB
Standard
Autoreclosure
Enabled
When Open Mode= Normal, allows re-closing of contact O61 to be activated
after a TRIP due to protection L (On)
Off
Motor Class
Allows the trip class of the motor to be selected from among: 5E, 10E, 20 E,
30E (page 68)
Contactor Delay
Defines the time waited, after the open command of contact O61, before
the fault is considered to be still present and action is taken by sending a
command to the Trip coil of the CB. The value is given in seconds and can
be set within the range: 0.1 s to 1 s, in 0.1 s steps
0,1
Autoreclosure
Time
Defines the time waited after the open command of contact O61, before
this latter is closed. The value is given in seconds and can be set within the
range: 1 s to 1000 s, in 1 s steps
60
