ABB | SACE Tmax XT
12 | © 2019 ABB | 1SDH002039A1002 - ECN000093027 - Rev. A Overview of Ekip Touch | 2 - Models and Versions
Ekip G Hi-Touch
Figure 8
Ekip G Hi-Touch is available in a single version: Ekip G Hi-Touch LSIG, and has all the functions of the Ekip
Touch family by default.
Functionality Page
Standard protections 79
Voltage protections 50
Voltage advanced protections 53
Frequency protections 57
Power protections 60
ROCOF protections 66
Adaptive protections 67
Standard Measurements 97
Ekip Measuring Measurements 101
Class 1 Power & Energy Metering 104
Datalogger 105
Network Analyzer 107
