ABB | SACE Tmax XT

Supporting software and

documents

Different softwares and documents are available; the majority are free of charge and are designed to facilitate,

optimize and extend the functions and conﬁgurations of Ekip Touch in your installation:

NOTE: some of the documents mentioned in the next table refer to SACE Emax 2, but can

also be used with SACE Tmax XT5

Ekip Connect 3

ABB software to interface with Ekip Touch and other low voltage devices

(link)

Ekip Connect Mobile

ABB APP to interface with Ekip Touch using a smartphone / tablet via Bluetooth

(link)

Ekip View

ABB software which supervises the communication network, analyzes the trend of the electricity values and

monitors the plant conditions (1SDH001276r0001)

NOTE: the link launches the software package download, which requires about 1.3 Gb of

space.

e-Design

ABB software suite

(link) which includes the following tools:

• DOC, to design the single-line diagrams of low and medium voltage electrical installations, choose the

operating and protection devices and check and coordinate the protections

• CAT, for technical / commercial cost estimating of ABB products

• Curves, for drawing, calibrating and printing the trip curves of the protection devices

• OTC, for assessing the thermal behavior of the switchgear and sizing its fans and air conditioners

• UniSec, for conﬁguring medium voltage switchgear

Front CAD

Software comprising libraries of block graphics for ABB panel-making products to be used with the latest

versions of AutoCAD, AutoCAD LT, IntelliCAD

(link)

NOTE: the link launches the software package download, which requires about 190 Mb of

space.

Ekip Link

Introduction to the Ekip Link switchgear monitoring system (1SDC200031l0202)

Network Analyzer

Introduction to the Network Analyzer measuring and analysis system (1SDC200037l0202)
