ABB | SACE Tmax XT
Internal accessories | 8 - Ekip Signalling 1K195 | © 2019 ABB | 1SDH002039A1002 - ECN000093027 - Rev. A
Input parameters
The input can be configured in the Settings-Modules-Ekip Signalling 1K-Input menu:
Parameter Description Default
Polarity
Defines whether the input is interpreted as ON by the Trip unit when it
is open (Active open) or when it is closed (Active Closed)
Active closed
Delay
Minimum activation time of the input before status change is
recognized; the delay is given in seconds and can be set within range:
0 s to 100 s, in 0.01 s steps
NOTES :
• status change is not recognized if the input deactivates before
this time has elapsed
• if delay = 0 s status change must still be more than 300 µS
0.1 s
Output parameters
The output can be configured in the Settings-Modules-Ekip Signalling 1K-Output menu:
Parameter Description Default
Signal source
Event which activates the output and switches the contacts.
Different protection proposals, statuses and thresholds are available
on the display; the Custom mode can be configured via Ekip Connect
so as to extend the solutions and combine several events
None
Delay
Minimum duration of the presence of the source before the output is
activated; the delay is given in seconds and can be set within range: 0
s to 100 s, in 0.01 s steps
NOTE:
• the output will not be switched if the source is deactivated
before this time has elapsed
• if delay = 0 s the source must still be present for longer than
300 µS
0 s
Contact Type
Defines the rest status of the contact with source not present
between: open (NO) and closed (NC)
NO
Latched
(1)
Allows the output (and relative status led) to be kept activated (On) or
deactivated (Off) when the event disappears
Off
min Activation
Time
(2)
Defines the minimum closing time of the contact following the rapid
presence of sources
• Source duration < min. activation = contact is activated for the
minimum activation time
• Source duration ≥ min. activation = contact is activated for as long
as the source persists
Choose between: 0 ms, 100 ms, 200 ms
0 ms
(1)
deactivate the latchings of the outputs used if Ekip Measuring is used for the Power Controller function
(2)
if Ekip Measuring is used for the Power Controller function, the Pulse Mode option will also be available; if
selected, the output is kept activated for a set time that depends on the function, regardless of whether the
event that activated it persists
About
The About-Modules menu contains the specific menu of the module, in which the statuses of the input (On/
Off) and output (Open/Closed) are present.
Test
The output test command can be executed in the Test menu (see page 121).
