42/23-55 EN Rev. 1 SCC-C Sample Gas Cooler Operator’s Manual 21
Troubleshooting
Problem Cause Remedy
Ambient temperature
< 5 °C
• Heat the downstream assemblies.
Sample gas cooler
overloaded
• Ensure sample gas inlet conditions (see page 7) and
operating specifications (see page 27) are followed.
Defective peristaltic pump • Replace the peristaltic pump.
Defective pump hose • Replace hose (see page 16).
Cooling performance
inadequate although
sample gas cooler not
overloaded
• Provide adequate cooling air flow.
• The fan should operate.
• Maintain the minimum clearance with respect to
adjacent units or walls (see page 8).
• Clean condenser fins (see page 20).
Condensate in the
Sample Gas Outlet
Compressor motor
breaker tripped
• Eliminate the thermal overload caused by the sample
gas flow or excessive ambient temperature.
• Clean condenser fins (see page 20).
• Ensure sample gas inlet conditions (see page 7) and
operating specifications (see page 27) are followed.
• Allow the compressor to cool before the next run.
Sample Gas Flow
Blocked
Sample gas paths
contaminated
• Contamination can result from the failure to remove
dust or sublimates. Ensure dust is removed before
the sample gas enters the sample gas cooler;
eliminate sublimates prior to this point.
• Clean the sample gas lines and cooling system; con-
sider the effects of corrosion and reduced service life
when using chemical cleaners and flush with an inert
gas in order to avoid any cleaning agent influence on
measurement results.
Defective temperature
controller
• Replace temperature controller. Inaccurate
Temperature
Indication
Refrigerant escaping • Send the sample gas cooler to the service
department for service.
Power supply
disconnected
• Reconnect the sample gas cooler power supply. Defective Sample
Gas Cooler
Defective motor breaker
or winding, i.e. the
compressor motor is not
running
• Measure the electrical resistance of the motor
winding (guide value is approx. 40 Ω).
• If the difference is considerable (with measuring
circuit open or short-circuited), then the motor
breaker should be replaced.
• If the motor winding is defective, send the sample
gas cooler to the service department for repair.
