ABB Zenith ZTSCT Series User Manual

ABB Zenith
21
ZTSCT / ZBTSCT Operation & Maintenance Manual
Testing
(cont’d)
Closed Transition
ABB Zenith Closed Transition Transfer Switches are designed
to Transfer the Load between two available sources without
interrupting power to the Load (Make-Before-Break).
Paralleling of the two sources occurs within a predefined
window of synchronization and lasts less than 100 millisec-
onds. The initial Source is then disconnected.
Initiating a Closed Transition
When a Test is initiated, the controller initiates the Time
Delay Source 2 Start (Engine Start Timer “P”) cycle. Upon
completion of the (P) time delay, an Engine start Signal
is sent to Source 2. When Source 2 voltage and frequency
reach the preset “Restore” values, the time delay to open
Source 1 timer (W) begins its timing cycle. After the (W)
time delay, the ATS closes into Source 2 only after the
controller ensures the proper phase relationship between
the two Sources. After the ATS closes into Source 2, the
SE limit switch becomes activated. The controller initiates
a transfer signal through the SCR-NO which opens the ATS
out of Source 1. The SNO limit switch activates. The ATS
has now closed into Source 2 position without interrupting
the load.
Retransfer with Closeed Transition
Deactivating the Test Switch initiates
the re-transfer. When
Source 1 voltage and frequency reach the preset “Restore”
values, the time delay to open Source 2 timer (T) begins
its timing cycle. After the (T) time delay, the ATS closes
into Source 1 only after the controller ensures the proper
phase relationship between the two Sources. After the
ATS closes into Source1, the SN limit switch becomes
activated. The controller initiates a transfer signal through
the SCR-EO which opens ATS out of Source 2. The SEO
limit switch activates. The ATS has now closed back into
Source 1 position without interrupting the load.
The ATS defaults to an open transition transfer when
Source 1 fails. Closed transition transfer is not possible
with only one source available. If the optional Transition
Mode Selector (TMS) is available, one can select an Open
Transition Transfer or a Closed Transition Transfer when
both Sources are available.
If while in Closed Transition Mode, the ATS fails to open
the source it is attempting to “transfer out of ” within
100 milliseconds, an Alarm will sound and the source
that the ATS just closed into will be opened leaving the
ATS in its initial source while disabling all other transfer
operations until the problem is corrected and the “Fail
to Open Lockout Reset” has been pressed.
A signal will be provided (STE) to Shunt Trip the Generator
Circuit Breaker if the Transfer Switch remains closed into
both Sources for more than 325 milliseconds. The load
will then be fed by the Source 1. The maximum time that
the two Sources would be parallel, under these conditions,
is less than 500 milliseconds. Before operating the Closed
Transition Transfer Switch, the condition must be corrected
and the Shunt Trip reset. Refer to procedure for servicing
the Switch after Shunt Tripping occures.
The unit is Factory set to accomplish transfer within
5 electrical degrees.
Requires an Isochronous Governor with an operating
frequency of 60+/- 0.2 Hz.
Requires a Shunt Trip Breaker on the Generator set
with a response time not exceeding 50 milliseconds.
A periodic test of the transfer switch under load conditions is recommended to insure proper operation.
(See National Electric Code articles 700 and 701)
NOTICE

ABB Zenith ZTSCT Series Specifications

General

Poles	2, 3, 4
Series	ZTSCT Series
Manufacturer	ABB
Amperage Range	30A to 4000A
Voltage	Up to 600 VAC
Operation	Automatic
Standards	UL 1008, CSA C22.2 No. 178
Enclosure	NEMA 1, 3R, 4, 12
Transfer Type	Open or Closed Transition
