Page #146 background image
146
Changing the batteries
Insert two new batteries (type AAA, LR 03, AM 4 or micro).
The minus (-) ends of the batteries must match up with the minus
marks in the battery compartment.
Re-attach the battery compartment cover.
The three hooks on the underside of the cover must engage with the
slots along the edge of the battery compartment. The cover is then just
loosely held in position.
Slide the battery compartment cover back into place.
It locks with an audible CLICK.
AC_CP_LCM_Manual_EN-UK final.indd 146_CP_LCM_Manual_EN-UK final.indd 146 20.6.2007 11:04:3420.6.2007 11:04:34

Table of Contents

Other manuals for Accu-Chek Compact Plus

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Accu-Chek Compact Plus and is the answer not in the manual?

Accu-Chek Compact Plus Specifications

General IconGeneral
Measurement Range10-600 mg/dL
Sample Size1.5 µL
Test Time5 seconds
Automatic CodingYes
DisplayLCD
Measurement MethodElectrochemical
Battery Type2 x AAA
Battery LifeApprox. 1000 tests
Data TransferInfrared (IR)
Storage Conditions-25°C to +70°C
Operating Conditions10-40°C, 10-90% RH
