Accu-Chek Compact Plus Reference Manual

5
Intended use
Accu-Chek Softclix Plus Finger pricker
Finger pricker with adjustable depth setting for obtaining capillary blood
from a fingertip or earlobe and, when a special AST cap is used, from
alternative sites such as the ball of the thumb.
The Accu-Chek Softclix Plus finger pricker is intended only for
patient self-monitoring by a single person. It must not be used
to collect blood in a multi-patient setting as it does not
incorporate any features to guard against cross-infections.
AC_CP_LCM_Manual_EN-UK final.indd 5_CP_LCM_Manual_EN-UK final.indd 5 20.6.2007 11:03:5420.6.2007 11:03:54

Accu-Chek Compact Plus Specifications

General

Measurement Range	10-600 mg/dL
Sample Size	1.5 µL
Test Time	5 seconds
Automatic Coding	Yes
Display	LCD
Measurement Method	Electrochemical
Battery Type	2 x AAA
Battery Life	Approx. 1000 tests
Data Transfer	Infrared (IR)
Storage Conditions	-25°C to +70°C
Operating Conditions	10-40°C, 10-90% RH
