Acer AOD270 User Manual

Machine Maintenance Procedures 3-33
Microphone Removal 0
Prerequisite:
LCD Bezel Removal
1. Find the microphone (A) on the LCD module (Figure 3-33).
Figure 3-33. Microphone and Camera Module Locations
2. Remove the microphone from the LCD module as shown in Figure 3-34.
NOTE:
NOTE:
Use care not to damage the microphone.
Figure 3-34. Microphone Removal
C
A
B
B

Acer AOD270 Specifications

General

Processor	Intel Atom N2600
Processor Speed	1.6 GHz
Storage	320 GB HDD
Display Size	10.1 inches
Graphics	Intel GMA 3600
Operating System	Windows 7 Starter
Battery Life	Up to 8 hours
RAM	1GB DDR3
Display Resolution	1024 x 600
Battery	6-cell Li-ion
Wireless	802.11b/g/n
