Acer Aspire M3970 User Manual

Chapter 5 97
PS2 Connector(KB/MS)
VGA Connector
HDMI
Connector
Pin Signal Name
1KDATA
2,6 NC
3GND
4 5V_PS2
5KCLK
7MDATA
8,12 NC
9GND
10 5V_PS2
11 MCLK
13,14,15,16,1
7
GND
Pin Signal Name
1RED
2GREEN
3BLUE
4NC
5,6,7,8,10 LOUT1_L
9 5V_VGA
11 NC
12 SDA
13 HSYNC
14 VSYNC
15 SCL
Pin Signal Name
1 HDMI_TXDP2_C
2GND
3 HDMI_TXDN2_C
4 HDMI_TXDP1_C
5GND
6 HDMI_TXDN1_C
7 HDMI_TXDP0_C
8GND
9 HDMI_TXDN0_C
10 HDMI_TXCP_C
11 GND
12 HDMI_TXCN_C
13 NC
