Acer G195W User Manual

EN-13
USER CONTROLS
Power Switch / Power LED:
To turn the monitor ON or OFF.
Lights up to indicate the power is turned ON.
Using the Shortcut Menu
Press the function button to open the shortcut menu. The shortcut menu lets you
quickly select the most commonly accessed settings.
Empowering:
Press the Empowering Key to open the Acer eColor Management OSD and access
the scenario modes.
AUTO Auto Adjust:
Press this button to activate the Auto Adjustment function. The Auto Adjustment
function is used to set the HPos, VPos, Clock and Focus.
MENU OSD functions
Press this botton to activate the OSD menu.
Volume Up / Down
Press to adjust volume (Only Audio-Input Model)(Optional)
INPUT Input Key
Use Input key to select from different video sources that may be connected to
your monitor.
(a) VGA input (b) DVI input (c) HDMI input
As you cycle through the sources you will see the following messages on right top
side of screen to indicate currently selected input source. It may take 1 or 2
seconds for the image to appear.
VGA or DVI or HDMI
If either VGA or DVI input is selected ,but the VGA and DVI cables are not con-
nected, a floating dialog box indicates:
“No Cable Connect” or “No Signal”

Acer G195W Specifications

General

3D	No
Aspect ratio	16:10
Display diagonal	19 \
Display resolution	1440 x 900 pixels
Display technology	LCD
Contrast ratio (dynamic)	12000000:1
Display number of colors	-
Viewing angle, horizontal	160 °
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1440 x 900 (WXGA+)
On/off switch	Yes
DVI-D ports quantity	0
Product color	Black
Panel mounting interface	100 x 100 mm
Power consumption (standby)	- W
Power consumption (typical)	13.5 W

Weight and Dimensions

Depth (without stand)	117.1 mm
Width (without stand)	494 mm
Height (without stand)	400.1 mm
Weight (without stand)	3990 g
