Acer H243 User Manual

Acer Acer –LCD-H243H
39
03 Exploded Diagram
3.1 H243H_SCREW_LIST
ITEM PN Description
Q'T
Y(P
CS)
Fixed
T(kg*cm)
Remark
1
509146306
200R
SCREW,P,CROSS,W/WAS
,M3*6,Zn-Cc
7
6.5±0.5
For
NVBD/PWRBD/HDMI
2
509216608
110R
SCREW,F,CROSS,M4*8,B
LACK,NL,ROHS(NYLOK
)
4
12±1
For Hingle toBack cover
3
509412610
500R
SCREW B CROSS T
T-4*10 BLK ROHS
3
8.5±0.5
For Hingle to Stand Front
4
509000000
700R
BOLT,#4-40x11.8,Ni 4
4.0±0.25
For D-SUB CON&DVI
3.2. LCD Exploded drawing (All)
