Acer Acer –LCD-H243H
44
4.5 White screen
White Screen
Check LVDS
Cable Insert OK?
Change LVDS
Cable
Check VLCD is
+5V?
Check Panel
Enable of U104
Check Q101,
Q104, Q105, R105,
R108
Check LVDS cable
U104 Fail
Workmanship
LVDS cable NG
Panel NG
Q101, Q104, Q105,
R105, R108 fail
OK
OK
OK
OK
NG
OK
NG
NG
NG
NG
NG
