Acer H7530D User Manual

H7530/H7530D
Condential
3-2
3-2 Main Procedure
No Symptom Procedure
1 No Power
- Ensure the Power Cord and AC Power Outlet are securely connected
- Ensure all connectors are securely connected and aren’t broken
- Check LVPS
- Check Lamp Driver
- Check Main Board
2
Auto Shut Down
- Check LED Status
a. Thermal/Fan Failure : Temp LED (lights or ashes red), Power
LED (lights red)
- Check Thermal Switch
- Check Thermal Sensor Board
- Check Fan
- Check Main Board
b. Lamp Failure : Lamp LED (lights red), Power LED (lights blue)
- Check Lamp
- Check Lamp Driver
- Check Main Board
c. Color Wheel Failure: Lamp LED (ashes red), Power LED
(lights blue)
- Check Color Wheel
- Check Photo Senor
- Check Main Board
3 No Light On
- Ensure all connectors are securely connected and aren’t broken
- Check Lamp Cover
- Check Interrupt Switch
- Check Lamp Module
- Check Lamp Driver
- Check LVPS
- Check Main Board
- Check Color Wheel
- Check Photo Sensor Board (Color Wheel)

Acer H7530D Specifications

General

Number of colors	1.073 billion colors
Projection distance	1 - 4 m
Vertical scan range	0 - 85 Hz
Horizontal scan range	0 - 100 kHz
Projection technology	DLP
Contrast ratio (typical)	-
Screen size compatibility	-, 300\
Projector native resolution	1080p (1920x1080)
Projector brightness (economic mode)	1600 ANSI lumens
Digital zoom	8 x
Focal length range	- mm
Resolution	1600 x 1200 pixels
Audio input	1
Aspect ratio	4:3, 16:9
RS-232 ports	0
Power requirements	110 V AC/220 V AC
Connectivity technology	Wired
Lamp type	P-VIP
Lamp power	230 W
Light source type	Lamp
Service life of light source	2500 h
Service life of light source (economic mode)	4000 h
HD-Ready	Yes
Analog signal format system	NTSC, PAL, SECAM
Built-in speaker(s)	No
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power consumption (standby)	- W
Noise level	- dB
Product color	Silver
Market positioning	Home cinema

Weight and Dimensions

Weight	3129 g
